8TP (24 single phase ways) outdoor distribution with room for two 3 phase meters and a ripple relay. The multiclip distribution system can be configured with MCBs and RCDs on the same rail (if you need to use all 24 ways, we would recommend using another 600 x 300 x 132mm base for E/N bar and cable duct). Meters or relay not included. Meter cabinet is 185mm deep (with extension frame), distribution cabinet is 132mm deep.
Specifications:
- Dimensions: 600 x 800 x 185mm
- Main Switch size: Schneider 100A
- Code: ADA3-100A
- Range: Cubo P
- Base Materials: Polycarbonate
- Cover Materials: Polycarbonate
- Wall Fastening Possible: True
- IP Rating: IP66
- IK Rating : IK08
- Chemical Resistance: True
This includes:
- 63A - 160A Main Switch
- 8TP Multiclip distribution
- E/N Bars to suit
Options:
Bases can be joined on the short or long side.
For stp. dwg. and dxf. files, please click here.
For trade pricing and stock information, please go to the re-seller login.
